SECTION 5 - DRIVE TRAIN
8990462
644E-42,944E-42
195
FIGURE 5-13. FRONT AXLE - BRAKE (644E Prior to SN 0160039830, Excluding 0160036724,
0160036811, 0160036907 and 0160037012; 944E Prior to SN 0160040124, Excluding 0160034634,
0160036710, 0160036722, 0160036735 and 0160036738)
ITEM
PART NUMBER
QTY
DESCRIPTION
REV
1
Not Available
NLA
END SHIM, (no longer available, use Kit K1 for replacement), (644E
Axle and 944E Axle) (644E Prior to SN 332590; 944E Prior to SN
336083)
1
8036848
2
END SHIM, (644E Axle and 944E Axle) (644E SN 332590 through
675667; 944E SN 336083 through 675667)
1
70020413
2
END SHIM, (Axle) (SN 675668 to Present)
2
1321206
2
SNAP RING
3
8036321
6
CAP SCREW
4
Not Available
NLA
PRESSURE PIN, (no longer available, use Kit K1 for replacement),
(644E Axle and 944E Axle) (644E Prior to SN 332590; 944E Prior
to SN 336083)
4
1321244
6
PRESSURE PIN, (644E Axle and 944E Axle) (644E SN 332590 to
Present; 944E SN 336083 to Present)
5
8036859
6
O-RING
6
Not Available
NLA
FOUR-LIP RING, (no longer available, use Kit K1 for replacement),
(644E Axle and 944E Axle) (644E Prior to SN 332590; 944E Prior
to SN 336083)
6
8036861
6
U-RING, (644E Axle and 944E Axle) (644E SN 332590 to Present;
944E SN 336083 to Present)
7
Not Available
NLA
SEALING WASHER, (no longer available, use Kit K1 for
replacement), (644E Axle and 944E Axle) (644E Prior to SN
332590; 944E Prior to SN 336083)
7
8036849
2
SEALING WASHER, (644E Axle and 944E Axle) (644E SN 332590
to Present; 944E SN 336083 to Present)
8
8036320
2
O-RING
9
1321208
2
CUP SPRING
10
Not Available
NLA
SUPPORT RING, (no longer available, use Kit K1 for replacement),
(644E Axle and 944E Axle) (644E Prior to SN 332590; 944E Prior
to SN 336083)
10
8036855
2
BACKUP RING, (644E Axle and 944E Axle) (644E SN 332590 to
Present; 944E SN 336083 to Present)
11
Not Available
NLA
FOUR-LIP RING, (no longer available, use Kit K1 for replacement),
(644E Axle and 944E Axle) (644E Prior to SN 332590; 944E Prior
to SN 336083)
11
8036854
2
U-RING, (644E Axle and 944E Axle) (644E SN 332590 to Present;
944E SN 336083 to Present)
12
Not Available
NLA
SUPPORT RING, (no longer available, use Kit K1 for
replacement),(644E Axle and 944E Axle) ( 644E Prior to SN
332590; 944E Prior to SN 336083)
12
8036862
6
BACKUP RING, (644E Axle and 944E Axle) (644E SN 332590 to
Present; 944E SN 336083 to Present)
13
Not Available
NLA
PISTON, (no longer available, use Kit K1 for replacement), (644E
Axle and 944E Axle) ( 644E Prior to SN 332590; 944E Prior to SN
336083)
13
7027212
2
PISTON, (644E Axle and 944E Axle) (644E SN 332590 to Present;
944 SN 336083 to Present)
14
Not Available
NLA
FOUR-LIP RING,(no longer available, use Kit K1 for replacement),
(644E Axle and 944E Axle) ( 644E Prior to SN 332590; 944E Prior
to SN 336083)
14
8036852
2
U-RING, (644E Axle and 944E Axle) (644E SN 332590 to Present;
944E SN 336083 to Present)
15
1321207
8
CUP SPRING
16
8035958
2
SPACING WASHER
17
Not Available
NLA
OIL DAM, (no longer available, use Kit K1 for replacement), (644E
