23 Outlaw ® 7.1
R
Speed changes you. TM.
S
eCtiOn
7 • O
ptiOnS
& a
CCeSSOrieS
1. o
pTions
& a
ccessories
l
ocaTions
Fgure 7.1.1 shows the locaton of some of the components. Take tme to walk through your boat, locate
the features, and become famlar wth ther operaton and mantenance.
STANDARD & OPTIONAL EQUIPMENT LOCATIONS
(FIG. 7.1.1)
Item Location
6 - Disc CD Changer Cuddy, Port Side behind Seat Backrest
12V Receptacle Dash - Passenger Side (Port)
Anchor Holder w/ Strap Engine Compartment - Port Side
Auto Bilge Pump Engine Compartment - Under Engine
Battery Tray Engine Compartment - Strb Side on Floor
Blower Engine Compartment - Strb Side on Transom Wall
Courtesy Lights Cockpit - Side Panels
Depth Finder (Opt.) Dash - Driver Side (Strb) above Switch Panel
Freshwater Flush (Opt.) Engine Compartment - Strb Side, Under Starter
Fuel Fill & Vent Combo Midship - Port Side
Fuel Tank Cockpit - Under Center Floor
Fume Detector (Opt.) Gauge - Driver Side (Strb) Dash;
Detector - Engine Compartment
Fuse Panel Under Dash - Strb. Side
Garboard Drain Plug Transom - Under Drive Unit
Horn Bow - Strb Side
Hour Meter Dash - Integrated into Tachometer
Port-A-Pot (Opt.) Cuddy, under V-berth
Safety Switch w/ Lanyard Dash - Right Side of Shifter
Stereo Dash - Passenger Side (Port)
Stereo Amp. Cuddy, Port Side under seat cushion
Stereo Remote Driver Side (Strb) Dash
Swimplatform (Opt.) Transom - Above Drive Unit
Switch Panel Dash - Above Shifter
Transom Shower (Opt.) Strb. Stern above Swimplatform
Trim Tab Indicator Driver Side (Strb) Dash
