23 Outlaw
®
2.2
S
eCtiOn
2 • g
eneral
B
Oat
a
rrangeMent
R
Speed changes you.
TM.
3. b
asic
b
oaT
D
iMensions
anD
c
learances
(u
niTeD
s
TaTes
s
TanDarD
s.a.e.)
23 O
utlaw
s
pecificaTions
Overall length .................................................................23'6"
Overall length (w/ drve down)........................................25'3"
Overall length w/ swm Platform ....................................24'8"
Beam (wdth) .....................................................................8'4"
Draft (stern drve down) ..................................................... 39"
Draft (stern drve up n tralerng poston)...........................24"
Dry Weght .........................................................4,200 pounds
Fuel Capacty.......................................................... 80 gallons
h
eiGhT
D
iMensions
From keel
wthout Wndscreen.............................................................62"
keel To Top
Of Wndscreen.................................................................... 68"
From Waterlne
wthout Wndscreen.............................................................42"
From Waterlne to
Top of Wndscreen..............................................................48"
8’ 4”
Beam
(FIg. 2.2.3)
B
Oat
d
iMenSiOnS
and
C
learanCeS
(F
ig
. 2.2.1)
23'6"
25'3"
62"
68"
Specification measurements are approximate
and subject to variance.
S
tern
d
rive
(i
nBOard
-O
utBOard
) e
ngine
(F
ig
2.2.2)
sTERn DRIVE UnIT
(lOWER UnIT)
DRaFT
(stern Drve Down)
39"/99cm
WaTER lInE
hUll
(TRansOM)
EngInE
