23 O
utlaw
S
peCiFiCatiOnS
Overall length ..............................................................7.16 m
Overall length (w/ drve down).....................................7.69 m
w/std. swm Platform ....................................................7.52 m
Beam (wdth) ................................................................2.54 m
Draft (stern drve down) .................................................99 cm
Draft (stern drve up n tralerng poston)......................61 cm
Dry Weght.................................................................1,905 kg
Fuel Capacty......................................................... 302.8 lters
h
eight
d
iMenSiOnS
From keel
wthout Wndsheld.......................................................1.57 m
keel To Top
Of Wndsheld...............................................................1.73 m
From Waterlne
wthout Wndscreen......................................................1.07 m
Waterlne to Top
of Wndscreen...............................................................1.22 m
4. p
ropulsion
s
YsTeM
your boat s equpped wth a stern drve type
propulson system also known as an nboard-
outboard engne. (see Fgure 2.2.2) Ths type of
propulson system has the engne nsde the boat
secured to the hull's strngers at the rear end of
the hull. The stern drve unt, also called the lower
unt because t hangs below the hull, s part of the
propulson system that attaches to the outsde of
the hull or transom. The stern drve unt pvots to
steer the boat.
For engne operatng nstructons, see page 3.4.
B
Oat
d
iMenSiOnS and
C
learanCeS
(F
ig
. 2.3.1)
7.16 m
1.57 m
1.73 m
7.69 m
2.54 m
Beam
(FIg. 2.3.2)
5. p
ropellers
your Baja ® has been equpped wth a propeller
whch our tests have shown to be the best suted for
general use under normal condtons and load.
Under no circumstances use a propeller which
allows the engine to operate at higher than the
maximum RPM for your engine. (See the Engine
Operator's Manual.)
