WIKA CPC6000 - Manual (Page 53)

Automated Pressure Calibrator
CPC 6000
Mensor/WIKA Operating Instructions - CPC 6000 53
39 Errorno? {string} Returns CPC 6000 error code and text.
40 Filter {Off, Low, Normal, High} Sets the reading filter.
41 Filter? {string} Returns the reading filter.
42 Gasdensity {value} Sets the head pressure gas density in lb/ft^3.
43 Gasdensity? {value} Returns the head pressure gas density in lb/ft^3.
44 Gastemp {value} Sets the head pressure gas temperature in °F.
45 Gastemp? {value} Returns the head pressure gas temperature.
46 Gateway {string e.g. nnn.nnn.nnn.nnn} Sets the Ethernet gateway address.
47 Gateway? {string} Returns the Ethernet gateway address.
48 Height {value} Sets the head pressure height in inches.
49 Height? {value} Returns the head pressure height.
50 Highspeed {Yes or No} Sets the active channel to high speed mode:
.006% stablewindow and 1 second stabledelay.
51 ID? MENSOR,600,{ssssss},{
v.vv} Returns the instrument identity where {ssssss}
is the serial number, and {v.vv} is the software
version number.
52 IP {string e.g. nnn.nnn.nnn.nnn} Sets the IP address of the instrument.
53 IP? {string} Returns the IP address of the instrument.
54 Keylock {Yes or No} YES to lock, or NO to unlock the on-screen
keys.
55 Keylock? {Yes or No} Returns current keylock status as YES or NO.
56 List? Pri,X,X;Sec,X,X;Bar,1r> Returns list of available turndowns on installed
sensors in the active channel. X will be non-ex-
istent if the turndown is not available.
57 Listcal? PRI,{sn},{td},{mm/
dd/yyyy},{td},{mm/dd/
yyyy};SEC,{td},{mm/dd/
yyyy},{td},{mm/dd/yyyy}
Returns the serial number of each installed
transducer and calibration dates for each range.
58 Listrange? PRI,{td},{min},{max},{td},
{min},{max};SEC,{td},{min},{m
ax},{td},{min},{max} Returns the minimum and maximum ranges of
all installed sensors for the active channel.
