WIKA CPC6000 - Manual (Page 29)

Automated Pressure Calibrator
CPC 6000
Mensor/WIKA Operating Instructions - CPC 6000 29
6. Local Operation
6.1 General
This section describes the procedures for operating the CPC 6000 from the front panel. Instructions
for operating the device remotely from an external computer are covered in the next section,
Remote
operation . By following the procedures provided in these two sections and the Calibration section ,
you can expect your CPC 6000 to deliver maximum accuracy and dependability for many years of
useful service.
6.2 Keys and Tabs
Local operation is accomplished by observing the data presented in the display, then pressing the
on-screen [key] or [tab] for the desired function. Throughout this manual characters enclosed inside
square brackets [ ] represent the associated on-screen touch point.
6.3 Display Screen Features
Figure 6.3A provides a brief description of the features shown on a single channel display.
Figure 6.3A - Display Screen Features
