WIKA CPC6000 User Manual
Page 26
Automated Pressure Calibrator
CPC 6000
26
Mensor/WIKA Operating Instructions - CPC 6000
5.4 Rear Panel
Up to eight pneumatic pressure ports are located horizontally across the rear panel (Figure 5.4). Po-
sitioned to the right of the pressure ports are the Ethernet, RS-232 and GPIB connector, the off/on
switch, the line fuses, and a protective grill covering the ventilating fan.
Figure 5.4 shows a rear panel containing two solenoid valve regulator pneumatic modules. Rear panels
may differ depending on what modules are installed.
Figure 5.4 - Rear Panel
