46 Mensor/WIKA Operating Instructions - CPC 6000
7.1.2 [IEEE-488] Setup Screen
Press the [IEEE-488] tab to set up the IEEE address. Press the white box and a number keypad will
appear for you to enter your new IEEE address and then press [OK].
Figure 7.1.2 - [IEEE-488] Setup Screen
7.1.3 [Serial] Setup Screen
Press the [Serial] tab to set up the serial port parameters. These parameters should be set up to match
your host computer. Default settings are: 57600, 8,1, none parity, and no echo.
If the Echo check box is checked, the CPC 6000 will immediately echo back characters sent over the
serial port.
Figure 7.1.3 - [Serial] Setup Screen
