44 VS-3232DN - Installing and Using the Test Module to Troubleshoot Video Problems
10 Installing and Using the Test Module to
Troubleshoot Video Problems
The VS-3232DN includes a test module which acts as a signal generator and can
be used to diagnose video/audio issues in an operating environment.
The test module must be installed in the configuration before it can be used. When
installing the test module, the number of configured inputs and outputs must be
increased by one. For example:
•
If your VS-3232DN has four inputs and eight outputs, you must configure the
VS-3232DN as 5 x 9
•
If your VS-3232DN has 32 inputs and 32 outputs, you must configure the
VS-3232DN as 33 x 33
10.1 Installing the Test Module
To install the test module in the configuration:
1. Press ESC, ENT and LOCK together.
The following is displayed:
Configuration Device
2. Press ENT.
The following is displayed:
Test Board: 0 MaxInput:32 MaxOutput:32
where 0 indicates that the test module is not installed.
3. Using the numeric keys, press 1 to indicate that the test module is installed.
The TAKE button flashes.
4. Press TAKE.
5. Increase the number of configured inputs and outputs by one (see
Section 9 ).
The test module is now installed and may be used.
