VS-3232DN - Configuring the Number of Installed Input and Output Ports

Configuring the Number of Installed Input
and Output Ports

After installing or removing a module you need to set the number of input and

output ports so that the VS-3232DN recognizes the new configuration. Refer to

To set the number of input or output ports:

for an explanation of port numbering before setting the number of input

and output ports.

1. Press ESC, ENT and LOCK together.

The following is displayed:

Configuration Device

2. Press ENT.

The following is displayed:

Test Board: 0 MaxInput:32 MaxOutput:32

Note: The number of input and output ports can only be set in units of four, for

example, 4 x 4, 32 x 4 or 12 x 16, and not 5 x 4 or 12 x 17.

3. Using the numeric keys, enter the number of input and output ports installed.

The TAKE button flashes.

4. Press TAKE.

The number of installed ports is saved and the display reverts to the

output/input display.

5. Reboot the device by turning the power off and then on again.
