VS-3232DN - Defining the VS-3232DN 32x32 Digital Matrix Switcher 9
VS
-32
32D
N
–
D
e
fin
in
g
t
h
e
V
S
-3
232
D
N
32
x3
2
D
ig
it
a
l
M
a
tr
ix
S
wit
c
h
e
r
9
Figure 3 shows DVI cards installed as an example.
# Feature Function
1 AC Mains Power Module Fuse holder and power cord socket. Connect to the AC mains supply
2 IN 1~16 Connectors Connect to the relevant video sources, depending on the cards installed (1 to 16, see Section 6
3
)
IN 17~32 Connectors Connect to the relevant video sources, depending on the cards installed (17 to 32, see Section 6
4
)
TEST Module Signal generator module for testing video outputs (see Section 10
5
)
RESOLUTION DIP-switches Set the resolution for video generated by the Test module (see Section 10.2
6
)
RS-232 9-pin D-sub Port Connects to the remote operation PC or remote controller (see Section 6.1
7
)
NET Ethernet RJ-45
Connector Connect to a PC or controller via the Ethernet LAN (see Section 6.4
The LINK LED flashes when communication is active. The POWER LED lights when the interface
receives power
).
8 OUT 1~16 Connectors Connect to the relevant video acceptors, depending on the cards installed (1 to 16, see Section 6
9
)
OUT 17~32 Connectors Connect to the relevant video acceptors, depending on the cards installed (17 to 32, see Section 6
10
)
PATTERN Button Press the button repeatedly to change the video pattern generated by the Test module (see
Section 10.3
11
)
Test Module Output
Connector Connect to one of the relevant video inputs to aid in troubleshooting (see Section 10.4 )
