VS-3232DN - Using the Configuration Menus 35
HDMI plus Analog Audio Input Card
Parameter Options/Description Default
84.Audio Balance 0 to 100: sets the audio input channel balance 50
87.Audio Bass 0 to 100: sets the audio inout bass level 50
88.Audio Treble 0 to 100: sets the audio input treble level 50
91.Audio Mute MUTE: mutes the audio input
Non-MUTE: unmutes the audio input Non-MUTE
98.Audio Select Auto: audio signal selection is controlled by the presence or
absence of a plug in the 3.5mm mini jack
AUD-Embedded: HDMI audio is selected
AUD-Ex-Digital: S/PDIF audio is selected (only works on
HDMI plus S/PDIF card)
AUD-Ex-Analog: Analog audio from the 3.5mm mini jack is
selected (only works on HDMI plus analog audio card)
Auto
HDMI plus S/PDIF Audio Input Card
Parameter Options/Description Default
36.Reset
SubBoard Re-power: power cycles the port
Factory: performs a factory reset to default values of the port Re-power
98.Audio Select Auto: audio signal selection is controlled by the presence or
absence of a plug in the 3.5mm mini jack
AUD-Embedded: HDMI audio is selected
AUD-Ex-Digital: S/PDIF audio is selected (only works on HDMI
plus S/PDIF card)
AUD-Ex-Analog: Analog audio from the 3.5mm mini jack is
selected (only works on HDMI plus analog audio card)
Auto
8.2.3 Config Menu—Output Load Detection Display
This option displays a list of outputs and indicates which have loads attached to
them.
To display a list of outputs and attached loads:
1. Press MENU twice.
The following message is displayed:
start configuration menu
MENU to view setup, ENT to change them
2. Press MENU until the following is displayed:
OUT: 01 02 03 04 05 06 07 08 09 10 11
LOAD: Y X Y Y Y Y X Y Y Y X
Y indicates that a load is attached and X indicates that no load is detected
on the relevant output.
