12 VS-3232DN - Connecting the VS-3232DN
To install the VS-3232DN as illustrated in the example in Figure 4 :
1. Connect up to 32 DVI video sources (for example, computer graphics
sources).
In this example only two inputs and two outputs are connected.
2. Connect up to 32 DVI video acceptors, (for example, a plasma display and a
DVI LCD display).
3. If required, connect a PC or remote controller to the RS-232 port (see
Section 6.1 ) and/or the Ethernet port (see 6.4 Section
4. Connect the power cord.
).
We recommend that you use only the power cord that is supplied with the device (not
shown in
Figure 4 ).
5. If necessary, review and set the system configuration using the Menu (see
Section 8
Note: Given an input signal that is HDCP encoded, the VS-3232DN outputs a
signal only if the output port supports HDCP, (for example, HDMI input and DVI
with HDCP output).
).
6.1 Port Numbering
On all cards apart from the DVI dual link cards there are four physical ports. The
numbering of ports is sequential from top to bottom and left to right. Each DVI dual
link card provides two physical ports which causes the loss of two numbers in the
numbering sequence of that card only. A sample numbering is shown in Figure 5 .
