VS-3232DN - Operating Your Video Matrix Switcher 23
2. Enter additional output-input combinations.
The LCD display can show up to five pending actions (although the batch is
not limited to five actions):
In this example, input 9 is set to switch to output 6 and input 5 is set to switch to output
7.
09 => 06 05 => 07
3. After entering all output/input combinations, press the flashing TAKE button
to confirm the actions.
The inputs switch to the respective outputs as shown on the LCD display
and the TAKE LED is lit.
7.4.3 Turning an Output Off
Turning an output off means that there is no input switched to this output. This is
indicated on the display by the Input being blank underneath the relevant Output.
To turn an output off:
1. Press MENU.
The Menu buttons light and are enabled.
2. Press OFF (3) on the numeric keypad (see Figure 1 ).
The following message is displayed:
out__ => OFF
3. Use the numeric keypad to turn the required output off.
The output is turned off.
To turn an output off in the Confirm mode:
•
Repeat the steps above and then press the flashing TAKE button to confirm
the action
Alternatively, you can perform a switching operation (see Section 7.4.1 ) and set
the input to 00.
