June 2004 TargetPro™ User's Manual
FIGURE 30. TargetPro Configuration dialog box and default settings
Table 8 explains the available parameters in the TargetPro Configuration
dialog box.
TABLE 8. Tools
→Configuration settings for displayed nav data
Parameter Block Meaning / Comments
Speed
(radio buttons)
This affects the way the recorded speed of the towfish or
survey vessel for the logged contact is reported in the
Cursor Status window. When Auto (the default) is selected,
the recorded speed is the displayed speed. If you choose
Manual, you are telling TargetPro to override the Auto
setting with the value you specify here.
Speed Corrected Display: When a check mark is in this
box, any logged contacts will be transferred to the Target
utility with rectilinear images based on the towfish speed.
Checking the box again turns it off (the default state).
Chapter 5: TargetPro Menu 56
