34
2-FUNCt USER INPUT/FUNCTION KEY PARAMETERS
DISPLAY PARAMETER USER SETTING
USrACt USER ACTIVE STATE
USEr-1 USER INPUT 1
USEr-2 USER INPUT 2
F1 FUNCTION KEY 1
F2 FUNCTION KEY 2
SEC-F1 2nd FUNCTION KEY 1
SEC-F2 2nd FUNCTION KEY 2
3-dISPLY DISPLAY PARAMETERS
DISPLAY PARAMETER USER SETTING
Color LINE 1 DISPLAY COLOR
d-LEV DISPLAY LEVEL
d-Cont DISPLAY CONTRAST LEVEL
LINE 1 LINE 1 DISPLAY
UNItS UNITS MNEMONIC OFF LISt
UNItS1 SEGMENT 1
UNItS2 SEGMENT 2
UNItS3 SEGMENT 3
ACCESS LINE 2 LOOP ACCESSIBILE ITEMS NO YES
INPUt b2-d2
totAL S3
Hi b3-d3
Lo S4
LISt b4-d4
S1 Color
b1-d1 d-LEV
S2 d-Cont
FUNCt LINE 2 USER FUNC. ACCESS. ITEMS NO YES
rEL r-2
bAt r-3
r-tot r-4
r-HI r-34
r-Lo r-234
r-HL r-ALL
r-1 Print
COdE SECURITY CODE
4-SCNdrY SECONDARY FUNCTION PARAMETERS
DISPLAY PARAMETER USER SETTING
HI-AS MAX ASSIGNMENT
HI-t MAX CAPTURE DELAY TIME
LO-AS MIN ASSIGNMENT
LO-t MIN CAPTURE DELAY TIME
dSP-t DISPLAY UPDATE TIME
5-totAL
TOTALIZER PARAMETERS
DISPLAY PARAMETER USER SETTING
dECPNt TOTALIZER DECIMAL POINT
t bASE TOTALIZER TIME BASE
SCLFAC TOTALIZER SCALE FACTOR
Lo Cut TOTALIZER LOW CUT VALUE
PWrUP TOTALIZER POWER-UP RESET
6-SEtPNt SETPOINT OUTPUT PARAMETERS
DISPLAY PARAMETER USER SETTING USER SETTING USER SETTING USER SETTING
SELECt SETPOINT SELECTION S1 S2 S3 S4
ASSIGN SETPOINT SOURCE
ACtION ACTION FOR SETPOINT
SEtPNt SETPOINT VALUE
bn-dEV SETPOINT BAND/DEVIATION VALUE
HYStEr HYSTERESIS FOR SETPOINT
t-ON ON TIME DELAY SETPOINT
t-OFF OFF TIME DELAY SETPOINT
LOGIC OUTPUT LOGIC
rESEt RESET ACTION
StndbY STANDYBY OPERATION
Annun OUTPUT ANNUNCIATOR LIGHT
Color CHANGE COLOR
brnAct PROBE BURN-OUT ACTION
7-SErIAL
SERIAL COMMUNICATIONS PARAMETERS
DISPLAY PARAMETER USER SETTING
USb USB PORT
tYPE TYPE
bAUd BAUD RATE
dAtA WORD LENGTH
PArItY PARITY
Addr ADDRESS
dELAY TRANSMIT DELAY
Abrv ABBREVIATED
OPt PRINT OPTION NO YES
INPUt Signal Input
totAL Total Value
HILO Max & Min
SPNt Setpoint Values
8-AnLOut ANALOG OUTPUT PARAMETERS
DISPLAY PARAMETER USER SETTING
tYPE ANALOG TYPE
ASSIGN ANALOG ASSIGNMENT
ANALOG LO ANALOG LOW
ANALOG HI ANALOG HIGH
UPdAtE ANALOG UPDATE TIME
brnAct PROBE BURN-OUT ACTION
