TROUBLESHOOTING
PROBLEM REMEDIES
No Display At Power-Up Check power level and power connections
No Display After Power-Up Check Module 3: d-LEU , d-Cont , and LINE 1 program settings.
Program Locked-Out Check for Active User Input, programmed for PLOC . Deactivate User Input.
Enter proper access code at COdE 0 prompt.
No Line 1 Display Check Module 3: LINE 1 program setting.
No Line 2 Display Check Module 3: ACCESS program settings.
No Programmable Units Display Check Module 3: UNItS Mnemonic program settings.
Incorrect Input Display Value Check Input Jumper Setting, Input Level, and Input Connections.
Verify Module 1 program settings.
Contact factory
Display of OLOL , ULUL , Short , OPEN , or “ . . . . ” See General Meter Specifications, Display Messages.
Modules or Parameters Not Accessible Check for corresponding plug-in option card.
Verify parameter is valid in regard to previous program settings.
Error Code: ErrKEY Keypad is active at power up. Check for depressed or stuck keypad. Press
any key to clear Error Code.
Error Code: EE PAr
Error Code: EE Pdn
Parameter Data Checksum Error. Press any key to clear Error Code, verify
all program settings and cycle power. Contact factory if Error Code returns at
next power-up.
Error Code: ErrPro Parameter Data Validation Error. Press any key to clear Error Code, verify all
program settings and cycle power. Contact factory if Error Code returns at
next power-up.
Error Code: EE CAL Calibration Data Validation Error. Contact factory.
Error Code: EE Lin Linear Output Card Data Validation Error. Press any key to clear Error Code
and cycle power. If Error Code returns at next power-up, replace Linear
Option Card or contact factory.
PARAMETER VALUE CHART Programmer ________________ Date ________
PAX2A Meter# _____________ Security Code ________
1-InPUt INPUT SETUP PARAMETERS
DISPLAY PARAMETER USER SETTING
rANgE INPUT RANGE
SCALE TEMPERATURE SCALE
ICE ICE POINT CONPENSATION
rAtE ADC CONVERSION RATE
dECPNt SCALING DECIMAL POINT
round DISPLAY ROUNDING
OFFSEt DISPLAY OFFSET
FILtEr DIGITAL FILTER
bANd DIGITAL FILTER BAND
POINtS SCALING POINTS
StYLE SCALING STYLE
INPUt 1 INPUT 1 SCALING VALUE
dISPLY 1 DISPLAY 1 VALUE
INPUt 2 INPUT 2 SCALING VALUE
dISPLY 2 DISPLAY 2 VALUE
INPUt 3 INPUT 3 SCALING VALUE
dISPLY 3 DISPLAY 3 VALUE
INPUt 4 INPUT 4 SCALING VALUE
dISPLY 4 DISPLAY 4 VALUE
INPUt 5 INPUT 5 SCALING VALUE
dISPLY 5 DISPLAY 5 VALUE
INPUt 6 INPUT 6 SCALING VALUE
dISPLY 6 DISPLAY 6 VALUE
DISPLAY PARAMETER USER SETTING
INPUt 7 INPUT 7 SCALING VALUE
dISPLY 7 DISPLAY 7 VALUE
INPUt 8 INPUT 8 SCALING VALUE
dISPLY 8 DISPLAY 8 VALUE
INPUt 9 INPUT 9 SCALING VALUE
dISPLY 9 DISPLAY 9 VALUE
INPUt 10 INPUT 10 SCALING VALUE
dISPLY 10 DISPLAY 10 VALUE
INPUt 11 INPUT 11 SCALING VALUE
dISPLY 11 DISPLAY 11 VALUE
INPUt 12 INPUT 12 SCALING VALUE
dISPLY 12 DISPLAY 12 VALUE
INPUt 13 INPUT 13 SCALING VALUE
dISPLY 13 DISPLAY 13 VALUE
INPUt 14 INPUT 14 SCALING VALUE
dISPLY 14 DISPLAY 14 VALUE
INPUt 15 INPUT 15 SCALING VALUE
dISPLY 15 DISPLAY 15 VALUE
INPUt 16 INPUT 16 SCALING VALUE
dISPLY 16 DISPLAY 16 VALUE
ScLISt ENABLE SCALE LIST
