Red Lion PAX2A - Manual (Page 27)

27
REGISTER
ADDRESS
REGISTER NAME LOW LIMIT HIGH LIMIT
FACTORY
SETTING
ACCESS COMMENTS
40428 Standby Operation 0 1 0 Read/Write 0 = No, 1 = Yes
40429 Annunciator 0 3 1 Read/Write 0 = Off, 1 = Normal, 2 = Reverse, 3 = Flash
40430 Color 0 7 0 Read/Write
0 = No Change, 1 = Green, 2 = Orange, 3 = Red,
4 = Grn/Org, 5 = Red/Org, 6 = Red/Grn,
7 = Line 1 Color
40431 Probe Failure Action (TC or RTD only) 0 1 0 Read/Write 0 = Off, 1 = On (only applies for TC or RTD input)
Setpoint 3
40441 Assignment 0 3 0 Read/Write 0 = None, 1 = Rel, 2 = Abs, 3 = Total
40442 Action 0 10 0 Read/Write 0=No, 1=Ab-HI, 2=Ab-LO, 3=AU-HI, 4=AU-LO, 5=dE-
HI, 6=dE-LO, 7=bANd, 8=bNdIn, 9=totLo, 10=totHI
40443 Hysteresis Value 1 65000 2 Read/Write 1 = 1 Display Unit
40444 On Time Delay 0 32750 0 Read/Write 1 = 0.1 Second
40445 Off Time Delay 0 32750 0 Read/Write 1 = 0.1 Second
40446 Output Logic 0 1 0 Read/Write 0 = Normal, 1 = Reverse
40447 Reset Action 0 2 0 Read/Write 0 = Auto, 1 = Latch1, 2 = Latch2
40448 Standby Operation 0 1 0 Read/Write 0 = No, 1 = Yes
40449 Annunciator 0 3 1 Read/Write 0 = Off, 1 = Normal, 2 = Reverse, 3 = Flash
40450 Color 0 7 0 Read/Write
0 = No Change, 1 = Green, 2 = Orange, 3 = Red,
4 = Grn/Org, 5 = Red/Org, 6 = Red/Grn,
7 = Line 1 Color
40451 Probe Failure Action (TC or RTD only) 0 1 0 Read/Write 0 = Off, 1 = On (only applies for TC or RTD input)
Setpoint 4
40461 Assignment 0 3 0 Read/Write 0 = None, 1 = Rel, 2 = Abs, 3 = Total
40462 Action 0 10 0 Read/Write 0=No, 1=Ab-HI, 2=Ab-LO, 3=AU-HI, 4=AU-LO, 5=dE-
HI, 6=dE-LO, 7=bANd, 8=bNdIn, 9=totLo, 10=totHI
40463 Hysteresis Value 1 65000 2 Read/Write 1 = 1 Display Unit
40464 On Time Delay 0 32750 0 Read/Write 1 = 0.1 Second
40465 Off Time Delay 0 32750 0 Read/Write 1 = 0.1 Second
40466 Output Logic 0 1 0 Read/Write 0 = Normal, 1 = Reverse
40467 Reset Action 0 2 0 Read/Write 0 = Auto, 1 = Latch1, 2 = Latch2
40468 Standby Operation 0 1 0 Read/Write 0 = No, 1 = Yes
40469 Annunciator 0 3 1 Read/Write 0 = Off, 1 = Normal, 2 = Reverse, 3 = Flash
40470 Color 0 7 0 Read/Write
0 = No Change, 1 = Green, 2 = Orange, 3 = Red,
4 = Grn/Org, 5 = Red/Org, 6 = Red/Grn,
7 = Line 1 Color
40471 Probe Failure Action (TC or RTD only) 0 1 0 Read/Write 0 = Off, 1 = On (only applies for TC or RTD input)
SERIAL COMMUNICATIONS PARAMETERS SEE MODULE 7 FOR PARAMETER DESCRIPTIONS
40481 USB Mode 0 1 0 Read/Write 0 = Configuration, 1 = Port
40482 Type 0 2 2 Read/Write 0 = RLC Protocol (ASCII), 1 = Modbus RTU,
2 = Modbus ASCII
40483 Baud Rate 0 5 5 Read/Write 0=1200, 1=2400, 2=4800, 3=9600, 4=19200, 5=38400
40484 Data Bits 0 1 1 Read/Write 0 = 7 Bits, 1 = 8 Bits
40485 Parity 0 2 0 Read/Write 0 = None, 1 = Even, 2 = Odd
40486 Address
0 99
247 Read/Write
RLC Protocol: 0-99
1 247 Modbus: 1-247
40487 Transmit Delay 0 250 10 Read/Write 1 = 0.001 Second
40488 Abbreviated Transmission (RLC only) 0 1 0 Read/Write 0 = No, 1 = Yes (Not used when communications type
is Modbus)
40489 Print Options (RLC only) 0 15 1 Read/Write
0 = No, 1 = Yes (Not used when communications type
is Modbus) Bit 0 – Print Input Value, Bit 1 – Print Total
Value, Bit 2 – Print Max & Min Values, Bit 3 – Print
Setpoint Values
40490 Load Serial Settings 0 1 0 Read/Write
Changing 40481-40487 will not update the PAX2A until
this register is written with a 1. After the write, the
communicating device must be changed to new PAX2A
settings and this register returns to 0.
ANALOG OUTPUT PARAMETERS SEE MODULE 8 FOR PARAMETER DESCRIPTIONS
40491 Type 0 2 1 Read/Write 0 = 0-20 mA, 1 = 4-20 mA, 2 = 0-10 V
40492 Assignment 0 9 0 Read/Write 0=NONE, 1=rEL, 2=AbS, 3=tOtAL, 4=HI, 5=LO, 6=S1,
7=S2, 8=S3, 9=S4
40493 Analog Low Scale Value (Hi word)
-199999 999999 0 Read/Write Display value that corresponds with 0 V, 0 mA or 4 mA
output 40494 Analog Low Scale Value (Lo word)
40495 Analog High Scale Value (Hi word)
-199999 999999 10000 Read/Write Display value that corresponds with 10 V or 20 mA
output 40496 Analog High Scale Value (Lo word)
40497 Update time 0 100 0 Read/Write 0 = Max update rate, 1 = 0.1 Second
40498 Probe Failure Action (TC or RTD only) 0 1 0 Read/Write 0 = Low Scale, 1 = High Scale (only applies for TC or
RTD input)
