Able, Ontents, Rdering – Red Lion PAX2A User Manual
Page 2: Nformation
2
Ordering Information . . . . . . . . . . . . . . . . . . . 2
General Meter Specifications . . . . . . . . . . . . . 3
Optional Plug-In Cards . . . . . . . . . . . . . . . . . . 5
Installing the Meter . . . . . . . . . . . . . . . . . . . . . 6
Setting the Jumpers . . . . . . . . . . . . . . . . . . . . 6
Installing the Plug-In Cards . . . . . . . . . . . . . . 7
Wiring the Meter . . . . . . . . . . . . . . . . . . . . . . . 7
Reviewing the Front Buttons and Display . . . . 9
PAX2A Display Loops . . . . . . . . . . . . . . . . . . 10
Programming the PAX2A . . . . . . . . . . . . . . . 11
PAX2A Modbus Register Table . . . . . . . . . . . 24
Factory Service Operations . . . . . . . . . . . . . 31
Troubleshooting Guide . . . . . . . . . . . . . . . . . 33
Parameter Value Chart . . . . . . . . . . . . . . . . . 33
Programming Overview . . . . . . . . . . . . . . . . . 35
T
able
O
f
C
OnTenTs
O
rdering
i
nfOrmaTiOn
Meter Part Numbers
MODEL NO.
DESCRIPTION
PART NUMBER
PAX2A
Universal DC Analog Input Panel Meter
PAX2A000
Option Card and Accessories Part Numbers
TYPE
MODEL NO.
DESCRIPTION
PART NUMBER
Optional
Plug-In
Cards
PAXCDS
Dual Setpoint Relay Output Card
PAXCDS10
Quad Setpoint Relay Output Card
PAXCDS20
Quad Setpoint Sinking Open Collector Output Card
PAXCDS30
Quad Setpoint Sourcing Open Collector Output Card
PAXCDS40
PAXCDC
RS485 Serial Communications Card with Terminal Block
PAXCDC10
Extended RS485 Serial Communications Card with Dual RJ11 Connector
PAXCDC1C
RS232 Serial Communications Card with Terminal Block
PAXCDC20
Extended RS232 Serial Communications Card with 9 Pin D Connector
PAXCDC2C
DeviceNet Communications Card
PAXCDC30
Profibus-DP Communications Card
PAXCDC50
PAXCDL
Analog Output Card
PAXCDL10
Accessories
SFCRD
2
Crimson PC Configuration Software for Windows 2000 and XP
SFCRD200
CBLUSB
USB Programming Cable Type A-Mini B
CBLUSB01
Notes:
1.
For Modbus communications use RS485 Communications Output Card and configure communication (tYPE) parameter for Modbus.
2.
Crimson software is available for free download from http://www.redlion.net/
