16
Pro
NO
Pro
3-dISPLY
P
Color
GrEEN
Ln1
Display
Color
d-LEV
4
dSP
Display
Intensity
LINE 1
INPUt
dSP
Line 1
Display
d-Cont
7
dSP
Display
Contrast
UNItS
OFF
dSP
Units
Mnemonic
ACCESS
NO
Ln2
Access
Line 2
INPUt
LOC
Ln2
Line 2 Input
Access
tOtAL
LOC
Ln2
Line 2 Total
Access
Hi
LOC
Ln2
Line 2 MAX
Access
Lo
LOC
Ln2
Line 2 MIN
Access
bn-dn
LOC
Ln2
Band and
Deviation
Value Access
CoLor
LOC
Ln2
Color
Access
d-LEV
LOC
Ln2
Display
Intensity
Access
d-Cont
LOC
Ln2
Display
Contrast
Access
FUNCt
NO
Ln2
Aux User
Functions
Access
COdE
0
dSP
Security
Code
Sn
LOC
Ln2
Setpoint
Value
Access
LISt
LOC
Ln2
Parameter
List A/B
Access
NO
YES
mOdule 3 - d
isplay
p
arameTers
(3-dISPLY)
PARAMETER MENU
Module 3 is the programming of the Main Display Loop, Parameter Display
Loop, Hidden Parameter Loop, and Full Programming lock-out. The large upper
display line value is configured by the “LINE1” parameter. The Units mnemonic
can be used to assign a custom display mnemonic to the upper display value.
When in the Main Display Loop, the available Line 2 displays (items configured
for d-rEd or d-ENt) can be consecutively read on lower display by repeatedly
pressing the D key. A left justified 3 character mnemonic indicates which
parameter value is being shown on the lower display. When in the Main Display
Loop the User keys ! and @ function as programmed in Module 2.
The Parameter display loop items can be accessed by pressing the P key. To
edit a main display line item, that is configured as d-ENt, the P key is pushed
and the unit enters a parameter edit mode in which the ! and @ key increments
or decrements the value.
Full Programming Mode permits all parameters to be viewed and modified.
This Programming Mode can be locked with a security code and/or user input.
LINE 1 DISPLAY COLOR
GrEEN rEd OrANGE
Enter the desired Display Line 1 and programmable Units Display color.
DISPLAY INTENSITY LEVEL
0 to 4
Enter the desired Display Intensity Level (0-4) by using the arrow keys. The
display will actively dim or brighten as the levels are changed. This parameter
also appears in the Parameter Display Loop when enabled.
DISPLAY CONTRAST LEVEL
0 to 15
Enter the desired Display Contrast Level (0-15) by using the arrow keys. The
display contrast / viewing angle will actively move up or down as the levels are
changed. This parameter also appears in the Parameter Display Loop when
enabled.
LINE 1 DISPLAY
INPUt totAL Hi Lo
S1 S2 S3 S4 NONE
Select the value to be assigned to the primary or top line of the meter display.
UNITS MNEMONIC
OFF LISt
This parameter allows programming of the display mnemonics characters.
Three individual characters may be selected from a preprogrammed list. The list
includes:
_ A b C d E F G H I J K L N O P Q R S t U V Y Z 0 1 2
3 4 5 6 7 8 9 c e g h i n o q r u - ° blank
LINE 2 MAIN, SECONDARY & HIDDEN DISPLAY LOOP
ACCESSIBLE ITEMS
NO YES
Select YES to program the display Line 2 accessible values. The default
setting of NO bypasses the programming of these values to shorten the module.
All of the individual Line 2 settings are retained.
The following values can be made accessible on Line 2 of the Main ( D key),
Parameter ( P key) and Hidden (P key following code entry) Display Loops.
Each of the following parameters can be configured for one of the following
settings. Not all selections are available for each parameter.
SELECTION DESCRIPTION
LOC Not viewed on display line
d-rEd View in Main Display Loop. Cannot change or reset.
d-ENt View and change (reset) in Main Display Loop
P-rEd View in Parameter Display Loop. Cannot change or reset.
P-ENt View and change (reset) in Parameter Display Loop
HidE View and change in Hidden Parameter Display Loop
LINE 2 INPUT ACCESS
LOC d-rEd d-ENt
When configured for d-ENt, the Input value can be reset (tare) using a front
keypad sequence. To reset (tare), push the P key while viewing the Input value
on Line 2. The display will show rEL NO. Press the ! key to select yYES
and then press P key. The display will indicate rESEt and then advance to
Parameter Display.
LINE 2 TOTAL ACCESS
LOC d-rEd d-ENt
When configured for d-ENt, the Total value can be reset using a front keypad
sequence. To reset, push the P key while viewing the Total value on Line 2. The
display will show r-tot NO. Press the ! key to select yYES and then press
P key. The display will indicate rESEt and then advance to Parameter Display.
