14
PROGRAMMING MODE LOCK-OUT
Programming Mode is locked-out, as long as activated (maintained action). A
security code can be configured to allow programming access during lock-out.
ZERO (TARE) DISPLAY
The Zero (Tare) Display provides a way to zero the Input Display value at
various input levels, causing future Display readings to be offset. This function
is useful in weighing applications where the container or material on the scale
should not be included in the next measurement value. When activated
(momentary action), rESEt flashes and the Display is set to zero. At the same
time, the Display value (that was on the display before the Zero Display) is
subtracted from the Display Offset Value and is automatically stored as the new
Display Offset Value. If another Zero (tare) Display is performed, the display
will again change to zero and the Display offset value will shift accordingly.
RELATIVE/ABSOLUTE DISPLAY
This function will switch the Input Display between Relative and Absolute.
The Relative is a net value that includes the Display Offset Value. The Input
Display will normally show the Relative unless switched by this function.
Regardless of the display selected, all meter functions continue to operate based
on relative values. The Absolute is a gross value (based on Module 1 DSP and
INP entries) without the Display Offset Value. The Absolute display is selected
as long as the user input is activated (maintained action) or at the transition of
the function key (momentary action). When the user input is released, or the
function key is pressed again, the input display switches back to Relative
display. (AbS) or (rEL) is momentarily displayed at transition to indicate which
display is active.
HOLD DISPLAY
The active display is held but all other meter functions
continue as long as activated (maintained action).
HOLD ALL FUNCTIONS
The meter disables processing the input, holds all
display contents, and locks the state of all outputs as long
as activated (maintained action). The serial port continues
data transfer.
SYNCHRONIZE METER READING
The meter suspends all functions as long as activated
(maintained action). When the user input is released, the
meter synchronizes the restart of the A/D with other
processes or timing events.
STORE BATCH READING IN TOTALIZER
The Input Display value is added (batched) to the Totalizer at transition to
activate (momentary action) and Line 2 flashes bAtCh. The Totalizer retains a
running sum of each batch operation until the Totalizer is reset. When this
function is selected, the normal operation of the Totalizer is overridden and only
batched Input Display values accumulate in the Totalizer.
SELECT TOTALIZER DISPLAY
The Totalizer display appears on Line 2 as long as
activated (maintained action). When the user input is
released, the previously selected display is returned. The
D or P keys override and disable the active user input. The Totalizer continues
to function including associated outputs independent of being displayed.
RESET TOTALIZER
When activated (momentary action), rESEt flashes and the Totalizer resets
to zero. The Totalizer then continues to operate as it is configured. This selection
functions independent of the selected display.
RESET AND ENABLE TOTALIZER
When activated (momentary action), rESEt flashes
and the Totalizer resets to zero. The Totalizer continues to
operate while active (maintained action). When the user
input is released, the Totalizer stops and holds its value. This selection functions
independent of the selected display.
ENABLE TOTALIZER
The Totalizer continues to operate while active
(maintained action). When the user input is released, the
Totalizer stops and holds its value. This selection functions
independent of the selected display.
SELECT MAXIMUM DISPLAY
The Maximum display appears on Line 2 as long as
activated (maintained). When the user input is released,
the previously selected display is returned. The D or P
keys override and disable the active user input. The Maximum continues to
function independent of being displayed.
RESET MAXIMUM DISPLAY
When activated (momentary action), rESEt flashes and the Maximum resets
to the present Input Display value. The Maximum function then continues from
that value. This selection functions independent of the selected display.
SELECT MINIMUM DISPLAY
The Minimum display appears on Line 2 as long as
activated (maintained). When the user input is released,
the previously selected display is returned. The D or P
keys override and disable the active user input. The Minimum continues to
function independent of being displayed.
USEr-n
PLOC
FNC
USEr-n
rEL
FNC Fn
rEL
FNC
USEr-n
d-rEL
FNC Fn
d-rEL
FNC
USEr-n
d-HLd
FNC
USEr-n
A-HLd
FNC
USEr-n
SYNC
FNC
USEr-n
bAt
FNC Fn
bAt
FNC
USEr-n
d-tot
FNC
USEr-n
r-tot1
FNC Fn
r-tot
FNC
USEr-n
r-tot2
FNC
USEr-n
E-tot
FNC
USEr-n
d-HI
FNC
USEr-n
r-HI
FNC Fn
r-HI
FNC
USEr-n
d-Lo
FNC
