LINE 2 MAX ACCESS
LOC d-rEd d-ENt
When configured for d-ENt, the Max Display value can be reset using a front
keypad sequence. To reset, push the P key while viewing the Hi value on Line 2.
The display will show r-Hi NO. Press the ! key to select yYES and then press
P key. The display will indicate rESEt and then advance to Parameter Display.
LINE 2 MIN ACCESS
LOC d-rEd d-ENt
When configured for d-ENt, the Min Display value can be reset using a front
keypad sequence. To reset, push the P key while viewing the Lo value on Line 2.
The display will show r-Lo NO. Press the ! key to select yYES and then press
P key. The display will indicate rESEt and then advance to Parameter Display.
LINE 2 PARAMETER LIST A/B ACCESS
LOC d-rEd d-ENt
P-rEd P-ENt HidE
When configured for d-ENt, the Parameter list can be selected using a front
keypad sequence. To select, push the P key while viewing LISt x”. “x” will
begin to flash, press the ! key to select “A” or “B” and then press P key. The
selected Parameter List will become active and the display will advance to
Parameter Display. See User Functions “Select Parameter List” for a description
of the list function. The Line 2 Parameter List provides a means of setting or
viewing the active parameter list.
LINE 2 SETPOINTS ACCESS
LOC d-rEd d-ENt
P-rEd P-ENt HidE
When configured for d-ENt, the P key must be pressed to select the item for
change before the ! and @ keys will increment or decrement the value.
LINE 2 BAND/DEVIATION ACCESS
LOC d-rEd d-ENt
P-rEd P-ENt HidE
When configured for d-ENt, the P key must be pressed to select the item for
change before the ! and @ keys will increment or decrement the value.
LINE 1 DISPLAY COLOR ACCESS
LOC P-rEd P-ENt HidE
When configured for P-ENt, Line 1 Color can be selected in the Parameter
Display by using the ! and @ keys while viewing Color.
DISPLAY INTENSITY ACCESS
LOC P-rEd P-ENt HidE
When configured for P-ENt, the display intensity can be selected in the
Parameter Display by using the ! and @ keys while viewing d-LEV.
DISPLAY CONTRAST ACCESS
LOC P-rEd P-ENt HidE
When configured for P-ENt, the display contrast can be selected in the
Parameter Display by using the ! and @ keys while viewing d-Cont.
LINE 2 USER FUNCTIONS ACCESSIBLE ITEMS
YES NO
Select YES to display the following list of User functions that can be made
available at the end of the Parameter (P-ENt) or Hidden (HidE) display loops.
The more critical and frequently used Functions should be first assigned to the
User Inputs and User Function keys. If more functions are needed than what can
be obtained with User Inputs, this feature will provide a means to provide that
access. Refer to module 2, 2-FUNCt for a description of the function.
rEL bAt r-tot r-HI r-Lo
r-HL r-1 r-2 r-3 r-4
r-34 r-234 r-ALL Print
PROGRAMMING SECURITY CODE
000 to 250
To activate either the Parameter or Hidden Parameter Display Loops, a
security code (1-250) must be entered. If a “0” security code is programmed,
pressing the P key takes you directly to the Full Programming Mode.
The Security Code determines the programming mode and the accessibility
of programming parameters. This code can be used along with the Program
Mode Lock-out (PLOC) in the User Input Function parameter (Module 2).
Two programming modes are available. Full Programming Mode allows all
parameters to be viewed and modified. Parameter Display Loop mode provides
access to those selected parameters, that can be viewed and/or modified without
entering the Full programming mode.
The following chart indicates the levels of access based on various CodE and
User Input PLOC settings.
SECURITY
CODE
USER INPUT
CONFIGURED
USER INPUT
STATE
WHEN P KEY IS
PRESSED
FULL PROGRAMMING
MODE ACCESS
0 not PLOC ———— Full Programming Immediate Access
>0 not PLOC ———— Enter Parameter
Display Loop
After Parameter
Display Loop with
correct code # at
COdE prompt.
>0 PLOC Active
Enter Parameter
Display Loop
After Parameter
Display Loop with
correct code # at
COdE prompt.
>0 PLOC Not Active Full Programming Immediate Access
0 PLOC Active
Enter Parameter
Display Loop
No Access
0 PLOC Not Active Full Programming Immediate Access
