26
REGISTER
ADDRESS
REGISTER NAME LOW LIMIT HIGH LIMIT
FACTORY
SETTING
ACCESS COMMENTS
40348 Line 2 Setpoint 3 Value Access 0 5 0 Read/Write 0=LOC, 1=d-rEd, 2=d-ENt, 3=P-rEd, 4=P-ENt, 5=HidE
40349 Line 2 S3 Band/Dev.Value Access 0 5 0 Read/Write 0=LOC, 1=d-rEd, 2=d-ENt, 3=P-rEd, 4=P-ENt, 5=HidE
40350 Line 2 Setpoint 4 Value Access 0 5 0 Read/Write 0=LOC, 1=d-rEd, 2=d-ENt, 3=P-rEd, 4=P-ENt, 5=HidE
40351 Line 2 S4 Band/Dev.Value Access 0 5 0 Read/Write 0=LOC, 1=d-rEd, 2=d-ENt, 3=P-rEd, 4=P-ENt, 5=HidE
40352 Reserved N/A N/A N/A N/A
40353 Reserved N/A N/A N/A N/A
40354 Reserved N/A N/A N/A N/A
40355 Reserved N/A N/A N/A N/A
40356 Line 2 Display Color Access 0 3 0 Read/Write 0=LOC, 1=P-rEd, 2=P-ENt, 3=HidE
40357 Line 2 Display Intensity Level Access 0 3 0 Read/Write 0=LOC, 1=P-rEd, 2=P-ENt, 3=HidE
40358 Line 2 Display Contrast Level Access 0 3 0 Read/Write 0=LOC, 1=P-rEd, 2=P-ENt, 3=HidE
40359 Line 2 Zero (Tare) Display Access 0 2 0 Read/Write 0=LOC, 1=P-ENt, 2=HidE
40360 Line 2 Batch Input to Totalizer Access 0 2 0 Read/Write 0=LOC, 1=P-ENt, 2=HidE
40361 Line 2 Reset Totalizer Access 0 2 0 Read/Write 0=LOC, 1=P-ENt, 2=HidE
40362 Line 2 Reset Max (Hi) Display Access 0 2 0 Read/Write 0=LOC, 1=P-ENt, 2=HidE
40363 Line 2 Reset Min (Lo) Display Access 0 2 0 Read/Write 0=LOC, 1=P-ENt, 2=HidE
40364 Line 2 Reset Max and Min Access 0 2 0 Read/Write 0=LOC, 1=P-ENt, 2=HidE
40365 Line 2 Reset Alarm 1 Access 0 2 0 Read/Write 0=LOC, 1=P-ENt, 2=HidE
40366 Line 2 Reset Alarm 2 Access 0 2 0 Read/Write 0=LOC, 1=P-ENt, 2=HidE
40367 Line 2 Reset Alarm 3 Access 0 2 0 Read/Write 0=LOC, 1=P-ENt, 2=HidE
40368 Line 2 Reset Alarm 4 Access 0 2 0 Read/Write 0=LOC, 1=P-ENt, 2=HidE
40369 Line 2 Reset Alarm 3 and 4 Access 0 2 0 Read/Write 0=LOC, 1=P-ENt, 2=HidE
40370 Line 2 Reset Alarm 2, 3 and 4 Access 0 2 0 Read/Write 0=LOC, 1=P-ENt, 2=HidE
40371 Line 2 Reset All Alarms (1-4) Access 0 2 0 Read/Write 0=LOC, 1=P-ENt, 2=HidE
40372 Line 2 Print Request Access 0 2 0 Read/Write 0=LOC, 1=P-ENt, 2=HidE
40373 Line 2 Security Code Value 0 250 0 Read/Write
SECONDARY PARAMETERS SEE MODULE 4 FOR PARAMETER DESCRIPTIONS
40381 Max (Hi) Capture Value Assignment 0 1 0 Read/Write 0 = Relative, 1 = Absolute
40382 Max (Hi) Capture Delay Time 0 32750 10 Read/Write 0 = Max Update Rate, 1 = 0.1Sec
40383 Min (Lo) Capture Value Assignment 0 1 0 Read/Write 0 = Relative, 1 = Absolute
40384 Min (Lo) Capture Delay Time 0 32750 10 Read/Write 0 = Max Update Rate, 1 = 0.1Sec
40385 Display Update (readings per second) 0 4 0 Read/Write 0 = 1, 1 = 2, 2 = 5, 3 = 10, 4 = 20
TOTALIZER PARAMETERS SEE MODULE 5 FOR PARAMETER DESCRIPTIONS
40391 Totalizer Decimal Point 0 4 3 Read/Write 0 = 0, 1 = 0.0, 2 = 0.00, 3 = 0.000, 4 = 0.0000
40392 Totalizer Time Base 0 3 1 Read/Write 0 = Second, 1 = Minute, 2 = Hour, 3 = Day
40393 Totalizer Scale Factor 1 65000 1000 Read/Write 1 = 0.001
40394 Totalizer Reset at Power Up 0 1 0 Read/Write 0 = No, 1 = Yes
40395 Totalizer Low Cut Value (Hi word)
-199999 999999 -199999 Read/Write
40396 Totalizer Low Cut Value (Lo word)
SETPOINT PARAMETERS
SEE MODULE 6 FOR PARAMETER DESCRIPTIONS
Setpoint 1
40401 Assignment 0 3 0 Read/Write 0 = None, 1 = Rel, 2 = Abs, 3 = Total
40402 Action 0 10 0 Read/Write 0=No, 1=Ab-HI, 2=Ab-LO, 3=AU-HI, 4=AU-LO, 5=dE-
HI, 6=dE-LO, 7=bANd, 8=bNdIn, 9=totLo, 10=totHI
40403 Hysteresis Value 1 65000 2 Read/Write 1 = 1 Display Unit
40404 On Time Delay 0 32750 0 Read/Write 1 = 0.1 Second
40405 Off Time Delay 0 32750 0 Read/Write 1 = 0.1 Second
40406 Output Logic 0 1 0 Read/Write 0 = Normal, 1 = Reverse
40407 Reset Action 0 2 0 Read/Write 0 = Auto, 1 = Latch1, 2 = Latch2
40408 Standby Operation 0 1 0 Read/Write 0 = No, 1 = Yes
40409 Annunciator 0 3 1 Read/Write 0 = Off, 1 = Normal, 2 = Reverse, 3 = Flash
40410 Color 0 7 0 Read/Write
0 = No Change, 1 = Green, 2 = Orange, 3 = Red,
4 = Grn/Org, 5 = Red/Org, 6 = Red/Grn,
7 = Line 1 Color
40411 Probe Failure Action (TC or RTD only) 0 1 0 Read/Write 0 = Off, 1 = On (only applies for TC or RTD input)
Setpoint 2
40421 Assignment 0 3 0 Read/Write 0 = None, 1 = Rel, 2 = Abs, 3 = Total
40422 Action 0 10 0 Read/Write 0=No, 1=Ab-HI, 2=Ab-LO, 3=AU-HI, 4=AU-LO, 5=dE-
HI, 6=dE-LO, 7=bANd, 8=bNdIn, 9=totLo, 10=totHI
40423 Hysteresis Value 1 65000 2 Read/Write 1 = 1 Display Unit
40424 On Time Delay 0 32750 0 Read/Write 1 = 0.1 Second
40425 Off Time Delay 0 32750 0 Read/Write 1 = 0.1 Second
40426 Output Logic 0 1 0 Read/Write 0 = Normal, 1 = Reverse
40427 Reset Action 0 2 0 Read/Write 0 = Auto, 1 = Latch1, 2 = Latch2
