18

Pro

NO

Pro

4-SCNdrY

P

HI-AS

rEL

SEC

HI-t

1.0

SEC

LO-AS

rEL

SEC

LO-t

1.0

SEC

dSP-t

2

SEC

MAX Capture

Assignment

MAX Capture

Time

MIN Capture

Assignment

MIN Capture

Time

Display

Update Rate

mOdule 4 - s

eCOndary

f

unCTiOn

p

arameTers

(4-SCNdrY)

PARAMETER MENU

MAX CAPTURE ASSIGNMENT

rEL

AbS

Select the desired parameter that will be assigned to the Max Capture.

MAX CAPTURE DELAY TIME

0.0

to

3275.0

seconds

When the Input Display is above the present MAX value for the entered delay

time, the meter will capture that display value as the new MAX reading. A delay

time helps to avoid false captures of sudden short spikes.

MIN CAPTURE ASSIGNMENT

rEL

AbS

Select the desired parameter that will be assigned to the Min Capture.

MIN CAPTURE TIME

0.0

to

3275.0

seconds

When the Input Display is below the present MIN value for the entered delay

time, the meter will capture that display value as the new MIN reading. A delay

time helps to avoid false captures of sudden short spikes.

DISPLAY UPDATE RATE

1

2

5

10

20

updates/second

This parameter configures the display update rate. It does not affect the

response time of the setpoint output or analog output option cards.

HI-AS

rEL

SEC

HI-t

1.0

SEC

LO-AS

rEL

SEC

LO-t

1.0

SEC

dSP-t

2

SEC
