Red Lion PAX2A User Manual
Page 25
25
REGISTER
ADDRESS
REGISTER NAME
LOW LIMIT HIGH LIMIT
FACTORY
SETTING
ACCESS
COMMENTS
40105
40205 Scaling Pt.1 Display Value (Hi word)
-199999
999999
0
Read/Write 1 = 1 display unit (disregard decimal point)
40106
40206 Scaling Pt.1 Display Value (Lo word)
thru
thru
Scaling Pts. 2 thru 15 Values
…
…
…
…
Registers 40107-40162 and 40207-40262 hold values
for Scaling Points 2 thru 15, and follow the same
ordering as Scaling Point 1.
40163
40263 Scaling Pt.16 Input Value (Hi word)
-199999
999999
0
Read/Write 1 = 1 in least significant digit (Input Range dependant)
40164
40264 Scaling Pt.16 Input Value (Lo word)
40165
40265 Scaling Pt.16 Display Value (Hi word)
-199999
999999
0
Read/Write 1 = 1 display unit (disregard decimal point)
40166
40266 Scaling Pt.16 Display Value (Lo word)
List A
List B
Setpoint Values
40167
40267 Setpoint 1 Value (Hi word)
-199999
999999
100
Read/Write 1 = 1 display unit (disregard decimal point)
40168
40268 Setpoint 1 Value (Lo word)
40169
40269 Setpoint 2 Value (Hi word)
-199999
999999
200
Read/Write 1 = 1 display unit (disregard decimal point)
40170
40270 Setpoint 2 Value (Lo word)
40171
40271 Setpoint 3 Value (Hi word)
-199999
999999
300
Read/Write 1 = 1 display unit (disregard decimal point)
40172
40272 Setpoint 3 Value (Lo word)
40173
40273 Setpoint 4 Value (Hi word)
-199999
999999
400
Read/Write 1 = 1 display unit (disregard decimal point)
40174
40274 Setpoint 4 Value (Lo word)
40175
40275 Setpoint 1 Band/Dev. Value (Hi word)
-199999
999999
0
Read/Write Applicable only for Band or Deviation Setpoint Action.
40176
40276 Setpoint 1 Band/Dev. Value (Lo word)
40177
40277 Setpoint 2 Band/Dev. Value (Hi word)
-199999
999999
0
Read/Write Applicable only for Band or Deviation Setpoint Action.
40178
40278 Setpoint 2 Band/Dev. Value (Lo word)
40179
40279 Setpoint 3 Band/Dev. Value (Hi word)
-199999
999999
0
Read/Write Applicable only for Band or Deviation Setpoint Action.
40180
40280 Setpoint 3 Band/Dev. Value (Lo word)
40181
40281 Setpoint 4 Band/Dev. Value (Hi word)
-199999
999999
0
Read/Write Applicable only for Band or Deviation Setpoint Action.
40182
40282 Setpoint 4 Band/Dev. Value (Lo word)
USER INPUT / FUNCTION KEYS
SEE MODULE 2 FOR PARAMETER DESCRIPTIONS
40301
User Input Active State
0
1
0
Read/Write 0 = Active Low, 1 = Active High
40302
User Input 1 Action
0
28
0
Read/Write
0 = NO 8 = d-tot 16 = r-HL 24 = r-4
1 = PLOC 9 = r-tot1 17 = dISP 25 = r-34
2 = rEL 10 = r-tot2 18 = d-LEV 26 = r-234
3 = d-rEL 11 = E-tot 19 = Color 27 = r-ALL
4 = d-HLd 12 = d-HI 20 = LISt 28 = Print
5 = A-HLd 13 = r-HI 21 = r-1
6 = SYNC 14 = d-Lo 22 = r-2
7 = bAt 15 = r-Lo 23 = r-3
40303
User Input 2 Action
0
28
0
Read/Write Same as User Input 1 Action
40304
User F1 Key Action
0
17
0
Read/Write
0 = NO 5 = r-HI 10 = r-1 15 = r-234
1 = rEL 6 = r-Lo 11 = r-2 16 = r-ALL
2 = d-rEL 7 = r-HL 12 = r-3 17 = Print
3 = bAt 8 = d-LEV 13 = r-4
4 = r-tot 9 = LISt 14 = r-34
40305
User F2 Key Action
0
17
0
Read/Write Same as User F1 Key Action
40306
User F1 Second Action
0
17
0
Read/Write Same as User F1 Key Action
40307
User F2 Second Action
0
17
0
Read/Write Same as User F1 Key Action
DISPLAY PARAMETERS
SEE MODULE 3 FOR PARAMETER DESCRIPTIONS
40331
Line 1 Display Color
0
2
0
Read/Write 0 = Green, 1 = Red, 2 = Orange
40332
Display Intensity Level
0
4
4
Read/Write 0 = Min.(off), 4 = Max.
40333
Display Contrast Level
0
15
7
Read/Write
40334
Line 1 Display
0
8
1
Read/Write 0 = None, 1 = Input, 2 = Total, 3 = Hi, 4 = Lo, 5 = S1,
6 = S2, 7 = S3, 8 = S4
40335
Units Mnemonic
0
1
0
Read/Write 0 = Off, 1 = List
40336
Units Digit 1 (Left)
0
46
0
Read/Write
0 = _ 7 = G 14 = O 21 = V 28 = 4
35 = e 42 = r
1 = A 8 = H 15 = P 22 = Y 29 = 5
36 = g 43 = u
2 = b 9 = I 16 = Q 23 = Z 30 = 6
37 = h 44 = -
3 = C 10 = J 17 = R 24 = 0 31 = 7
38 = i 45 = °
4 = d 11 = K 18 = S 25 = 1 32 = 8
39 = n 46 =
5 = E 12 = L 19 = t 26 = 2 33 = 9
40 = o
6 = F 13 = N 20 = U 27 = 3 34 = c
41 = q
40337
Units Digit 2 (Center)
0
46
0
Read/Write Same selections as Digit 1
40338
Units Digit 3 (Right)
0
46
0
Read/Write Same selections as Digit 1
40339
Line 2 Input Display Access
0
2
0
Read/Write 0=LOC, 1=d-rEd, 2=d-Ent
40340
Line 2 Totalizer Display Access
0
2
0
Read/Write 0=LOC, 1=d-rEd, 2=d-Ent
40341
Line 2 Maximum (Hi) Value Access
0
2
0
Read/Write 0=LOC, 1=d-rEd, 2=d-Ent
40342
Line 2 Minimum (Lo) Value Access
0
2
0
Read/Write 0=LOC, 1=d-rEd, 2=d-Ent
40343
Line 2 List Selection Access
0
5
0
Read/Write 0=LOC, 1=d-rEd, 2=d-ENt, 3=P-rEd, 4=P-ENt, 5=HidE
40344
Line 2 Setpoint 1 Value Access
0
5
0
Read/Write 0=LOC, 1=d-rEd, 2=d-ENt, 3=P-rEd, 4=P-ENt, 5=HidE
40345
Line 2 S1 Band/Dev. Value Access
0
5
0
Read/Write 0=LOC, 1=d-rEd, 2=d-ENt, 3=P-rEd, 4=P-ENt, 5=HidE
40346
Line 2 Setpoint 2 Value Access
0
5
0
Read/Write 0=LOC, 1=d-rEd, 2=d-ENt, 3=P-rEd, 4=P-ENt, 5=HidE
40347
Line 2 S2 Band/Dev.Value Access
0
5
0
Read/Write 0=LOC, 1=d-rEd, 2=d-ENt, 3=P-rEd, 4=P-ENt, 5=HidE
