Chapter 4 ____________________________________________ Basic Use of Lizard Setup Software
VAISALA_______________________________________________________________________ 77
Re-assigning Connectors
To quickly disconnect and reassign all the sensors or other equipment
already connected to the QML logger channels, proceed as follows:
1. Click the Disconnect All button.
2. Reassign the connectors either automatically by clicking the
Connect All button or manually as described in section
Assigning
I/O Connections on page 76 .
To disconnect only one sensor, double-click the text on the Connector
list and select from the combo box displayed.
Additional Sensors View
In the Additional sensors view, you can select and configure the serial
sensors to be included in your setup; see
Figure 32 on page 77 .
1004-067 Figure 32 Additional Sensors View
NOTE The information pane with general help information is available on all
the configurable items in case you need more detailed information.
