Ag Leader EZ-Guide 250 Getting Started Guide - Manual (Page 24)

Note: When the vehicle is on a guidance line, the line extends 1 km (0.6 miles) before Point A and 1 km beyond
Point B. This makes it easier to see where the next swath is, and to get online after the turn.
Mapping an AB Line
Drive to the start point of the master line. 1.
Set the A point: 2.
Press or until you have selected the icon. a.
Press . The A point is set. b.
Drive to the other end of the line. 3.
Ensure that the icon is selected and then press . The master AB Line appears. 4.
Turn left or right for the next swath. As you move toward the next swath, it appears on the screen and
turns orange to show that it is selected. 5.
A+ line
An A+ line is also a straight line. It is defined by a single point on the line (the A point) and the heading of the
line.
PATTERN EXAMPLE
20
