A P P E N D I X
B
GPS 5100 Receiver User Guide 5 9
Additional Equipment
Interface Requirements
B
B.1
Ag Leader Hardware
Table B.1 lists the interface requirements for connecting a GPS 5100
receiver to additional Ag Leader hardware.
Table B.1 Ag leader hardware requirements
Hardware Protocol NMEA
messages Baud Other Pos rate
YM2000 Yield Monitor NMEA GGA, VTG 4800 8-N-1 1 Hz
PF3000 Yield Monitor 1 NMEA GGA, VTG 4800 8-N-1 1 Hz
PF3000Pro Monitor
without internal GPS
1
1 Connect to Aux port.
NMEA GGA, VTG 4800 8-N-1 1 Hz
PFadvantage NMEA GGA, VTG 4800 8-N-1 1 Hz
INSIGHT NMEA GGA, VTG 4800 8-N-1 1 Hz
