GPS 5100 Receiver User Guide 3 7
Configuring the Receiver 4
NMEA settings
Three screens (NMEA1, NMEA2, and NMEA3) show what NMEA
messages are output from the port. Message types shown in upper case
are being output; message types shown in lower case are not.
For more information about NMEA message types, refer to the
document called NMEA-0183 Messages Guide for AgGPS Receivers
on the Trimble website (www.trimble.com).
Port output rate
This setting can be used to vary the NMEA and TSIP output rate. A
setting of 1 outputs one position each second.
ASAP equals the rate selected on the Filter and Position Rate screen
under the GPS Config menu. A setting of ASAP outputs positions five
or ten times every second. The default (factory) setting is 1 Hz.
