4 Configuring the Receiver
3 6 GPS 5100 Receiver User Guide
When using a Trimble SiteNet 900 radio, make sure that the
communication settings are correct in the receiver.
The default settings to use with the SiteNet radio are:
Changing the input or output port settings
1. From the Port A Config screen, press 2 until the Port-A
Input/Output screen appears:
2. Press 3 to activate the cursor.
3. Press 1 or 2 to change the value.
4. Press 3.
5. Repeat Steps 3 and 4 until you have set all the required values.
6. Press 4 to save all the changes.
7. Press 2 to move to the next screen.
Setting Description
Baud rate 38,400
Data bits 8
Parity None
Stop bits 1
åæ I RTCM 9600
8N1 0 NMEA 4800
