GPS 5100 Receiver User Guide 2 5
Installing the Receiver 3
35.1
Port A
Port A on the receiver has a 12-pin Deutsch DTM connector. For
cables, use the mating connector, Deutsch part number DTM06-12SA.
Viewed from outside the receiver, the Port A connector is on the left. It
is the port that is typically used to connect to an Autopilot system.
Table 3.3 Port A pinout
Pin Name/Function Comments
1 CAN A High I/O
2 Port 1 RS232 Tx OUT When held to ground during power up,
puts unit into Monitor mode
3 Port 1 RS232 Rx IN
4 PPS OUT
5 Signal GND Used for RS232 and other signals.
Should not be connected to
V– (battery negative)
6 Port 1 RTS OUT
7 Event OUT / Alarm OUT
8 Port 1 CTS IN
9 Event IN
10 V+ IN
11 V- IN
12 CAN A Low I/O
