GPS 5100 Receiver User Guide 3 5
Configuring the Receiver 4
The default port settings are:
Note – The AgRemote utility, when connected to an GPS 5100 receiver
receiver, automatically resets the receiver port communication settings
to 8-O-1 TSIP 115 K. This enables optimal communication with an
office computer. If the receiver is to work with an Autopilot system,
however, the receiver port communication settings must be 8-N-1 TSIP
38.4 K. To work with some other devices and software programs, the
receiver port communication settings must be 8-N-1 NMEA 4800. If
AgRemote has changed the settings, you will need to change them
back manually.
TEXTA See the description for the TEXTB setting (above). TEXTA input
outputs text on Port A. The default port settings are 8-N-1 TSIP
38.4 K. These may vary by product.
RTCM The receiver can accept RTCM data from an external DGPS
device, such as an external radio.
TSIP The receiver can accept or output TSIP data packets from the
port when using the optional AgRemote program or using a field
computer.
RtkLnk The receiver can accept real-time corrections (CMR data) from
an external device such as a Trimble radio.
Port A Port B
Baud rate In TSIP 38,400 TSIP 38,400
Out TSIP 38,400 TSIP 38,400
Data bits 8 8
Parity None None
Stop bits 1 1
Table 4.1 Port input settings (continued)
Setting Description
