3 Installing the Receiver
2 6 GPS 5100 Receiver User Guide
35.2
Port B
This port has the same connector as Port A, see above. Viewed from
outside the receiver, the Port B connector is on the right.
Table 3.4 Port B pinout
Pin Name/Function Comments
1 CAN B High I/O
2 Port 2 RS232 Tx OUT
3 Port 2 RS232 Rx IN
4 PPS OUT
5 Signal GND Used for RS232 and other signals.
Should not be connected to V–
(battery negative)
6 Port 2 RTS OUT
or Port 3 RS232 Tx OUT
7 Event OUT / Alarm OUT
8 Port 2 CTS IN or Port 3
RS232 Rx IN
9 Event IN
10 V+ IN / OUT Maximum output current = 1.25 A
11 V– IN / OUT Maximum output current = 1.25 A
12 CAN B Low I/O
