A P P E N D I X
A
GPS 5100 Receiver User Guide 5 5
Specifications
A
A.1
GPS 5100 Receiver
Table A.1 lists the physical characteristics of the GPS 5100 combined
GPS/DGPS receiver and antenna.
Table A.1 GPS 5100 receiver
Item Description
Size 300 mm (11.7 in) wide x 309 mm (12.05 in) deep x 70 mm
(2.73 in) high
Weight 2.1 kg
Power Nominal 350 mA at 12 V DC
Operating temperature –30 °C (–22 °F) through +70 °C (+158 °F)
Storage temperature –40 °C (–40 °F) through +85 °C (+185 °F)
Humidity Complies with Mil 810E Method 507.3 Procedure III Aggravated
Cyclic Humidity.
Ten 24 hour cycles of constant 95% RH, with cycling
temperature and dwells +30 °C (+86 °F) and +60 °C (140 °F).
Unit sealed to +/- 5 PSID
Casing Low-profile UV-resistant plastic. Dust-proof, waterproof, shock
resistant, with recessed protected connectors.
