Chapter 8 Rack Mounting the HP Netserver (2-Post)
73
Mounting the HP Netserver in the Rack
Follow these steps to mount the HP Netserver in the rack and secure it in place.
Once that is done, you can connect the front bezel to the Netserver chassis and
attach cables.
NOTE If other rack components are to be mounted in the rack below
the HP Netserver, install them before mounting the Netserver.
WARNING The HP Netserver LP 2000r weighs 38 lbs. (17.3 kg.) fully
loaded. To prevent an accident, use two people when placing
the Netserver into the rack.
1. With the help of at least one other person, lift the HP Netserver off the
table or pallet.
2. Position the mounting brackets over the holes (2nd & 5th) that you have
marked on the face of the two columns.
3. Insert a screw through the bottom hole on each bracket and tighten the
screws sufficiently to hold the HP Netserver in place while you insert and
tighten the remaining screws. See Figure 8-6 or Figure 8-7.
Figure 8-6. Flush Mounting the HP Netserver
