Chapter 5 Installing Additional Boards
39
4. Disconnect the power cables and any external cables connected to the
system.
If necessary, label each one to expedite reassembly.
WARNING The power supply will continue to provide standby current
to the HP Netserver LP 2000r until the power cable is
disconnected.
5. Remove the top cover.
Refer to Chapter 2, "Opening and Closing the HP Netserver."
CAUTION Wear a wrist-strap and use a static-dissipating work surface
connected to the chassis when handling components.
Ensure the metal of the wrist-strap contacts your skin.
6. Read the documentation included with the accessory board and follow any
special instructions.
NOTE Adding a PCI-to-PCI bridge board to the HP Netserver may
alter the Netserver’s boot order. This boot order can be
changed using the Setup Utility (press [F2] during the boot
process). Refer to "Boot Priority" earlier in this chapter.
7. Remove the PCI card cage:
a. Disconnect the PCI card cage fan from the system board.
See Figure 5-3.
b. Grip the PCI card cage by the fan and back edge, and firmly lift the
cage straight up to remove it. See Figure 5-3.
In lifting the card cage, you will feel initial resistance as the riser card
disconnects from the system board.
