Chapter 7 Rack Mounting the HP Netserver (4-Post)
59
Installing Slides in the Rack
1. Ensure the rack is stabilized.
For HP system /E or /U racks, pull the anti-tip foot forward out of the
bottom of the rack and lower the leveler screws to make firm contact with
the floor. See Figure 7-3.
Anti-tip Foot
Extended
Leveler
Screws (4)
Figure 7-3. Installing Slides in the Rack
2. Insert the rear slide mounting pins into holes you have marked on the rear
column. Then push in on the front of the slide and snap the front mounting
pins into holes marked on the front column.
