Chapter 1
Controls, Ports and Indicators
4
Rear Panel
The ports and connectors at the rear are listed below and shown in Figure 1-3.
•
The power connector accepts a standard power cable to connect the
HP Netserver LP 2000r with a UPS or the site power source. A second
power supply for redundancy is optional. Each power supply has its own
power cord connection.
•
The mouse port accepts a standard mouse with a PS/2 connector.
•
The keyboard port accepts a standard keyboard with a PS/2 connector.
•
The USB (2) ports are provided for devices other than the keyboard or
mouse.
•
The Parallel Port is a standard parallel port, which supports Extended
Capabilities Port (ECP)/Enhanced Parallel Port (EPP).
•
The Serial/Management Port is a standard serial port, which can be used
for a serial devices or management functions. For more information about
management functions, refer to the Server Management Reference Guide.
•
The dedicated serial port is a standard serial port.
•
The Video Port interface specifications are listed in Table A-4, "HP
Netserver Hardware Specifications" and Table A-5, "Video Display
Modes" of Appendix A, "Specifications."
•
The two LAN ports (LAN A and LAN B) are for the embedded controllers
based on Intel’s 82559 10/100 BaseT Fast Ethernet controller. Only LAN A
can be used for the LAN A Power On/Off remote management function.
Each LAN port has a RJ-45 LAN connector and two LEDs to indicate
LAN speed and valid connection or activity. Table 1-3 describes LAN
LED indicators. Refer to Chapter 10, "Configuring the HP Netserver," to
change configuration settings.
•
The external SCSI port provides access to external SCSI devices, typically
an external SCSI tape backup device.
