Chapter 7 Rack Mounting the HP Netserver (4-Post)
60
The slide mounting pins insert into the inside face of the rear column and
the front face of the front column. See Figure 7-3.
Removing Slides from the Rack
Follow these steps if you need to release the outer slide assembly after it is
installed in the rack.
1. Place your finger inside the slide to release the spring tab, as shown in the
example in Figure 7-4.
2. Press in on the spring tab and pull the outer slide assembly toward you at
the front of the rack.
View Rotated 90 Degrees CCW
Spring Tab
Figure 7-4. Releasing the Outer Slide Assembly
