Chapter 7 Rack Mounting the HP Netserver (4-Post)
61
Mounting the HP Netserver on the Slides
Follow these steps to mount the HP Netserver on the slides in the rack. Once the
Netserver is in the rack, you can connect the cables to the rear of the Netserver.
NOTE If other rack components are to be mounted in the rack below
the HP Netserver, install them before mounting the Netserver.
WARNING To prevent injury or equipment damage, ensure the anti-tip
foot (at the bottom of the rack) is pulled out and the leveler
screws on the rack’s corners are in firm contact with the floor.
1. Ensure the rack is stabilized.
For HP system /E or /U racks, pull the anti-tip foot forward out of the
bottom of the rack and lower the leveler screws to make firm contact with
the floor. See Figure 7-3.
CAUTION The HP Netserver LP 2000r weighs 38 lbs. (17.3 kg) fully
loaded. To avoid an accident, use two people when placing the
HP Netserver into the rack.
2. Mount the HP Netserver on the slides:
a. With the help of at least one other person, lift the HP Netserver by its
four corners off the floor or pallet.
b. Slowly insert the HP Netserver chassis into the slides and push it into
the rack until you feel resistance. See Figure 7-5.
c. Pull the HP Netserver out several inches, then press the stop release on
both slides to allow the Netserver to slide completely into the rack. See
Figure 7-6.
3. Secure the HP Netserver chassis to the rack with the thumbscrews.
