Chapter 5 Installing Additional Boards
38
Integrated
RA Board
I C
Connector 2
Figure 5-2. Integrated RA Board Location
Installing an Accessory Board
Use this procedure to install the accessory board.
NOTE For information about a specific PCI board type, refer to the
Readme file, Tested Products List, or Configuration Advisor on
your HP Netserver Navigator CD-ROM.
1. Log off all users and, if necessary, back up files.
For detailed instructions, see "Powering Down the HP Netserver," in
Chapter 1, "Controls, Ports and Indicators."
2. Press the power switch on the HP Netserver control panel to turn off power
when prompted by the operating system.
3. Pull out the anti-tip foot at the bottom of the rack. Then slowly slide the
HP Netserver chassis out from the rack as far as it can be extended.
It is not necessary to remove the HP Netserver from the rack to install an
accessory board.
