Chapter 13 Alternative Rack Mounting (4–Post)
116
Attaching the Front Bezel
1. Position the bezel in front of the HP Netserver LP 2000r, as shown in
Figure 13-8.
2. Hook the bottom edge of the bezel onto the chassis pins.
3. Close the bezel and press the top corners to engage the spring latches.
The spring latches should click when engaged.
A
B
Pin
Pin
Figure 13-8. Attaching the Bezel to the HP Netserver
Cabling Rack Components
After installing the HP Netserver in the rack, refer to the white paper entitled HP
Netserver High Density Rack Solutions Overview (LP 1000r and LP 2000r) to
cable the components in the rack enclosure. The white paper is available on HP’s
web site at the following URL:
http://www.hp.com/netserver/support
After cables are attached to rack components you can attach the Cable
Management Arm, as described in the next section.
