Chapter 6 Installing an Additional Processor
46
Primary Processor (CPU 1)
Secondary
Processor
(CPU 2)
Figure 6-1. System Board (top view)
Installing a Second Processor
This section provides the instructions for installing a second processor and its
heatsink on the system board. Figure 6-1 indicates the location of the primary and
secondary processors.
CAUTION Take the following precautions when installing processors:
•
Leave the processor in the anti-static bag until you are
ready to install it.
•
Wear an anti-static wrist strap and use a static-dissipating
work surface or grounding mat connected to the chassis
when handling components.
•
Before removing a processor from the anti-static bag,
touch a grounded, unpainted metal surface to discharge
static electricity.
