Item Values Explanation
PCL SUBMENU FORM LENGTH FORM LENGTH: Sets vertical spacing from 5 to 128 lines for
default paper size.
ORIENTATION ORIENTATION: Allows you to select default page orientation
as LANDSCAPE or PORTRAIT.
NOTE It is best to set the page orientation in the
program or printer driver. (Program and device-driver
settings override control-panel settings.)
FONT SOURCE FONT SOURCE: Allows you to select the font source as
INTERNAL, CARD SLOT 1, or EIO DISK.
FONT NUMBER FONT NUMBER: The device assigns a number to each font and
lists the numbers on the PCL Font List. The font number appears
in the Font # column of the printout. The range is 0 to 999.
FONT PITCH FONT PITCH: Selects the font pitch. This item might not appear,
depending on the font selected. The range is 0.44 to 99.99.
SYMBOL SET SYMBOL SET: Selects any one of several available symbol sets
at the device control panel. A symbol set is a unique grouping of
all the characters in a font. PC-8 or PC-850 is recommended for
line-draw characters.
APPEND CR TO LF APPEND CR TO LF: Select YES to append a carriage return to
each line feed that the device encountered in backward-
compatible PCL jobs (pure text, no job control). Some
environments, such as UNIX, indicate a new line using only the
line feed control code. Use this option to append the required
carriage return to each line feed.
SUPPRESS BLANK
PAGES SUPPRESS BLANK PAGES: When generating your own PCL,
extra form feeds are included that would cause one or more blank
pages to be printed. Select YES for form feeds to be ignored if the
page is blank.
MEDIA SOURCE
MAPPING MEDIA SOURCE MAPPING: Allows you to select and maintain
trays by number when you are not using the printer driver or when
the software program has no option for tray selection. CLASSIC:
Tray numbering is based on LaserJet 4 and older models.
STANDARD: Tray numbering is based on newer LaserJet
models.
Print Quality submenu
Some items on this menu are available in the program or printer driver (if the appropriate driver is
installed). Program and device-driver settings override control-panel settings. For more information,
see
Select the correct printer driver . In general, it is best to change these settings in the printer driver,
if applicable.
Item Values Explanation
SET REGISTRATION PRINT TEST PAGE
SOURCE
ADJUST TRAY [N]
Shifts the margin alignment to center the image on the page
from top to bottom, and left to right. You can also align the
image that is printed on the front with the image that is printed
on the back. Allows for one-sided and two-sided printing
alignment.
24 Chapter 2 Control panel ENWW
