1 Panel 4
2 Panel 5
3 Panel 6
Figure 20 Bin shelf numbering, right panels
Figure 21 shows the back panel bins. Each column has seven slots. Begin at the top, with the panel
corresponding to cluster 0, and load top to bottom and left to right. Continue loading each sequential
cluster, top to bottom and left to right.
NOTE:
The number of slots located in the back panel varies with the number of drive clusters installed.
