McDATA® 4Gb SAN Switch for HP p-Class BladeSystem user guide 95
Displaying port speeds
To display the speed of each port in the faceplate display, select View > View Port Speeds. Table 20 lists
the possible port speeds.
Displaying transceiver media status
To display transceiver media status, select View > View Port Media. Table 21 lists the port media states
and their meanings.
.
Table 20 Port speeds
State Description
Au Auto-detect
1Gb 1-Gbps transmission speed
2Gb 2-Gbps transmission speed
4Gb 4-Gbps transmission speed
Table 21 Port transceiver media view
Media icon Description
Optical SFP, online (green)
Optical SFP, offline (gray)
Copper SFP, online (green)
Copper SFP, offline (gray)
None Empty port, no transceiver installed. This is normal for internal ports (1–8).
