McDATA® 4Gb SAN Switch for HP p-Class BladeSystem user guide 71
Port Statistics data window
The Port Statistics data window displays port performance data for the selected ports. Click the Port Stats
data window tab in the faceplate display to open the Port Statistics data window. Refer to ” Port Statistics
data window ” on page 96 for a description of the Port Statistics data window entries.
The Statistics drop-down list is available on the Port Statistics data window, and provides different ways to
view detailed port information. Click the down arrow to open the drop-down list. Open the drop-down list
and select Absolute to view the total count of statistics since the last switch reset. Select Rate to view the
number of statistics counted per second over the polling period. Select Baseline to view the total count of
statistics since the last time the baseline was set. Click Clear Baseline to set the current baseline.
Port Information data window
The Port Information data window displays port detail information for the selected ports. Click the Port Info
data window tab in the faceplate display to open the Port Statistics data window. Refer to ” Port Information
data window ” on page 98 for a description of the Port Information data window entries.
NTP Server Address The IP address of the centralized NTP server. Ethernet
connection to NTP server is required.
FDMI HBA Entry Limit Maximum number of HBAs that can be registered with a
switch.
FDMI Enable Fabric Device Management Interface status. If enabled,
device information can be obtained, managed, and saved
through the fabric using Name Service Management Server
functions. McDATA Web Server will report any and all FDMI
information reported by the entry switch, if FDMI is enabled
on the entry switch. Refer to ” Displaying detailed device
information ” on page 48 for information about displaying
FDMI information.
Embedded GUI McDATA Web Server status. Enables or disables the web
server on the switch.
Inactivity Timeout Number of minutes the switch waits before terminating an
idle CLI session. Zero (0) disables the time out threshold.
GUI Mgmt Enabled Switch management application status. If disabled, the
switch cannot be managed using the application.
Telnet Enabled Telnet client status
SSH Enabled Secure Shell status. If enabled, an encrypted data path is
provided for CLI sessions.
SSL Enabled Secure Sockets Layer status. If enabled, encryption for switch
management application and CIM sessions is provided.
CIM Enabled Common Information Model status. The CIM agent is based
on the SNIA Storage Management Initiative Specification
(SMI-S), which is the standard for SAN management in a
heterogeneous environment.
FTP Enabled FTP status
Management Server
Enabled
Management server status
Table 9 Switch data window entries (continued)
Entry Description
