Operating the 5157 ACL Tape Drive 6-10
The display’s second line displays possible status conditions of the
library robotics:
•
Loader Idle
•
Fetch
•
Stow
•
Diag Active
•
Diag Complete
•
Taking Inventory
•
Elevator Home
•
Checking Drive(s)
•
Orphaned Cartridge
•
Trapped Cartridge
•
Scanning Labels.
The third line represents a map of the magazine. A 10-slot magazine
is shown. The number 1 shows the location of slot 1 (the front slot)
in the map. The number 10 shows the location of slot 10 (the rear
slot) in the map. Where a rectangle appears on this line, it indicates
that a cartridge is present in the corresponding slot of the magazine.
An underline means that there is no cartridge present in that slot.
6.5.4 Fault Screen
When a fault is detected, a screen similar to Figure 6-6 appears. At
the same time, either the Drive Fault or the Loader Fault LED is
illuminated.
Fault Code: XXXX Fault Code: XXXX
Error Description Error Description
ERP line 1 ERP line 1
ERP line 2 ERP line 2
Figure 6-6 Fault Screen
