Operating the 5157 ACL Tape Drive 6-19
6.10.6 Map Information Screen
When Map Info is selected, a screen similar to Figure 6-14 appears.
The location of the element being reported appears on line 1 in
place of the word ‘Location.’
Location
Location й й
Element Status Element Status
Label Status Label Status
XXXXXXXX XXXXXXXX к к
Figure 6-14 Map Info Submenu
Lines 1, 2, 3, and 4 of this screen are scrollable in unison. For each
scroll position, line 1 displays one of the following locations:
•
DLT1
•
Slot1
•
Slot2
•
Slot3
•
Slot4
•
Slot5
•
Slot6
•
Slot7
•
Slot8
•
Slot9
•
Slot10.
If the host software license permits fewer slots than the magazine
contains, and if reserved slots have been designated in accordance
with that license, or to use the Autoclean mode, a lesser number of
slots will be displayed. The procedure for designating reserved slots
is described in Chapter 5 - Installing and Configuring the 5157
ACL Drive.
