The 5157/5157 ACL S-Series Subsystems Installation/Users Guide
Appendix A
ix
The third line represents a map of the magazine. A 10-slot
magazine is shown. The number 1 shows the location of slot
1 (the front slot) in the map. The number 10 shows the
location of slot 10 (the rear slot) in the map. Where a
rectangle appears on this line, it indicates that a cartridge is
present in the corresponding slot of the magazine. An
underline means that there is no cartridge present in that
slot.
A.2.5 Entering the Menu Mode
When the Default Screen appears on the screen, enter the
Menu Mode by pressing the Enter button. The Main Menu
shown in Figure A-7 appears.
÷ ÷Load/Unload Load/Unload
Unlock Door Unlock Door
Show Status Menu Show Status Menu
Maintenance Menu Maintenance Menu к к
Figure A-7 Main Menu
A.2.6 Exiting the Menu Mode
To leave the menu mode and return to the Default Screen,
press the Escape button repeatedly. Each time the Escape
button is pressed, the display moves to a higher menu level.
When the Main Menu is visible, pressing the Escape button
once returns to the Default Screen.
A.2.7 The 5158 ACL/5157 ACL Menu Structure
Figures A-8 and A-9 show the structure of the 5158
ACL/5157 ACL menus.
